VC-25MX2-C 150 I

Resolution (MP)

25

Resolution (H x V)

5120 x 5120

Sensor

Gpixel GMAX0505 (Mono / Color)

Gpixel GMAX0505RF (NIR Enhanced)

Sensor Size (Diagonal)

12.8 mm x 12.8 mm (18.1 mm)

Optical Format

1.1”

Sensor Type

High Speed CMOS Image Sensor

Pixel Size

2.5 µm x 2.5 µm

Interface

CXP-12 x 4

Max Frame Rate

(8 bit)

CXP-6 x 4

93.1 fps

CXP-10 x 4

145.6 fps

CXP-12 x 4

150.2 fps

Exposure Time (1 µs step)

1 µs – 60 s

Partial Scan (Max Speed)

9022 fps at 4 Lines

Pixel Data Format

Mono 8 / 10 bit

Color GB Bayer 8 / 10 bit

Electronic Shutter

Global

Digital Gain

1x – 32x

Black Level Control

0 – 63 LSB at 10 bit

Trigger Synchronization

Free Run, Hardware Trigger, Software Trigger or CXP

External Trigger

3.3 V – 24.0 V, Logical Level Input, Optically Isolated

Software Trigger

Asynchronous, Programmable via Camera API

Dynamic Range

61 dB

Dimension

80 mm x 80 mm x 69.4 mm

Weight

560 g

Temperature

Operating: 0° C – 40° C

Storage: -40° C – 70° C

Lens Mount

C Mount

Power

External

11 – 24 V DC, Typ 14 W

PoCXP

24 V DC, Minimum of two PoCXP cables required

Compliance

CE, FCC, KC
